UpPro Series

Spider’s UpPro series of hoists were the first man-rated, UL-listed 2,200 lb and 5,500 lb hoists available on the market.

With a rugged, cast aluminum exterior, the UpPro series is designed for durability and simplicity of operation. UpPro hoists are available in multiple speed variations, including GHS models (Guided High Speed), offering speeds up to 60 feet per minute for elevator installation applications.

Models are available supporting both single and three phase power, as well as a range of voltages.

×
    Overspeed Safety Locks (OSL)

    Specifications

    Part NumberPayloadRope SizeWeightEasy TestElectric SwitchCompatible With
    OSL5081,323 lb (600 kg)8 mm15.4 lb (7 kg)P508
    OSL508E1,323 lb (600 kg)8 mm15.4 lb (7 kg)P508
    OSL508T1,323 lb (600 kg)8 mm15.4 lb (7 kg)P508
    OSL8091,764 lb (800 kg)9 mm15.4 lb (7 kg)P809
    OSL809E1,764 lb (800 kg)9 mm15.4 lb (7 kg)P809
    OSL809T1,764 lb (800 kg)9 mm15.4 lb (7 kg)P809
    OSL10102,205 lb (1,000 kg)10 mm15.4 lb (7 kg)P1009/P1010
    OSL1010E2,205 lb (1,000 kg)10 mm15.4 lb (7 kg)P1009/P1010
    OSL1010T2,205 lb (1,000 kg)10 mm15.4 lb (7 kg)P1009/P1010
    OSL25145,512 lb (2,500 kg)14 mm44 lb (20 kg)P2514/P2314

    Additional Details

    • All UpSafe OSLs are designed to stop movement automatically should descent speeds exceed 98 ft/minute (30 m/min).
    • The addition of an electrical switch to the UpSafe OSL allows the hoist to be electrically shutoff automatically if an activation occurs.
    • The UpSafe OSL-T is the same robust design as the standard OSL, however it allows simpler inspection in any application.
    Inclination Safety Locks (ISL)

    Specifications

    Part NumberRope SizeInclination LevelWeightCompatible With
    ISL5088 mm14°15.4 lb (7 kg)P508
    ISL101010 mm14°15.4 lb (7 kg)P1009/P1010

    Additional Details

    UpSafe ISLs are designed to stop movement automatically should the hoist ever be inclined by more than 14°
